Offener Rahmen-Dieselgenerator

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator

Alle Kategorien

Offener Rahmen-Dieselgenerator

Wasser-Pumpen-Satz

Treten Sie mit uns in Verbindung

Mr. Jason Jiang

power01@sanrock.com.cn

0086 17357052522

Kontaktieren Sie uns jetzt

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator

Markenbezeichnung:	SANROCK POWER
Modellnummer:	SPDG20KW
MOQ:	1 Satz
Preis:	Chat with supplier now for more details.
Verpackungsdetails:	Nacktpaket für Maschinen, Holzkastenpaket für Ersatzteile oder Kundennachfrage.
Zahlungsbedingungen:	MoneyGram, Western Union, T/T, D/P, D/A, L/C

Einzelheiten

Beschreibung des Produkts

Einzelheiten

Herkunftsort:

Zhejiang, China

Zertifizierung:

CE;ISO

Document:

Produktname:

Generatorensatz offenen Typs / Generatorensatz offenen Typs

Frequenz:

50Hz/60Hz

Stromspannung:

48 V, 110 V, 220 V, 230 V, 240 V, 380 V, 400 V, 415 V, 480 V

Zylinder:

3/4/6/12 – Je nach Leistung

Zylindernummer:

3,4,6,8,12 Zylinder

Phase-Nummer und Anschluss:

3-phasiges 4-drahtes System

Kühlsystem:

Wasserkühlung

Maß des Satzes (Millimeter):

1485*700*1000mm~7300*2440*2800mm

Nettogewicht des Satzes (Kilogramm):

Spezifiziert

Nennleistung (KW/1500 U/min):

5-2250KVA

Geschwindigkeit:

1500/1800 U/min

Anhängertyp, stiller Typ, Containertyp, super leiser Typ, offener Frame, tragbarer Typ, mobiler Typ,

Nennleistung:

20 kW, 30 kW, 40 kW, 50 kW, 80 kW, 100 kW, 200 kW, 300 kW, 800 kW, 1000 kW, 1200 kW, 1500 kW, 1800 k

Anwendung:

Fabrik, Gebäude, Farm, Bank usw.

Verwendung:

Gemeinsame Einheiten, Bereitschaftsstelle

Schlaganfall:

Anschlag vier

Logistik:

Transport ganzer Maschinen oder Demontagetransport; See- oder Bahntransport

Versorgungsmaterial-Fähigkeit:

100000Set/Monat

Hervorheben:

25kva diesel generator industrial

open frame diesel generator set

manufacturing diesel generator with warranty

Beschreibung des Produkts

Durability: The exposed steel frame offers superior protection for the core components and simplifies maintenance and repairs.
Portability: Most models are mounted on a wheel kit (trailer), making them relatively easy to move around a worksite or transport between locations.
In summary, a 20KW open-frame generator is a workhorse solution best suited for demanding environments where cost-effectiveness, durability, and easy serviceability are more important than quiet operation.
Industrial and Manufacturing
Backup Power for SMEs: Acts as an emergency power supply for small to medium-sized workshops, factories, and warehouses to prevent production stoppages and protect machinery during power cuts.
Primary Power for Remote Sites: Serves as the main power source for remote industrial operations like mining camps, forestry operations, and quarry sites.

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 8

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 9

Applicable Industries
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant,
Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company.

Product descriptions from the supplier
100KVA 150KVA 200KVA 300KVA 400KVA 500KVA 700KVA Diesel Genset
"Contact us for specific product details or customized requirements"

Product Description

Technical parameters of diesel generator set
Generator set model:SPDG20KW
Steady state voltage adjustment rate (%):≤± 1
Generator power:20kW/25kVA
Voltage fluctuation rate (%):≤ ± 0.5
Power factor:COSΦ = 0.8 (lagging)
Transient voltage adjustment rate (%):＋20 ～－15
Output voltage:400V/230V
Voltage stabilization time (s):≤1
Generator set current:36A
Steady state frequency adjustment rate (%):≤ ± 1
Rated frequency:50Hz
Frequency fluctuation rate (%):≤ ± 0.5
Rated speed:1500rpm
Transient frequency adjustment rate (%):+ 10 ~ -7
Fuel grade:(standard) 0 # light diesel (normal temperature)
Frequency stabilization time (S):≤3
Diesel generator size:1620*620*1380(L*W*H mm
Diesel generator fuel consumption (100% load):224g/kW·h
Diesel generator weight:600kg
Diesel generator volume(LP7m):95dB(A)
Technical parameters of diesel engine
Cooling method: Closed water-cooling
Oil supply method: direct injection
Engine cylinder number: 4 / L Type
Speed regulation method: Mechanical
Bore stroke: 102*120mm
Intake method: Natural inhalation
Compression ratio: 16.5:1
Overload capacity: 110%
Start method:DC 24V Electric start
Diesel engines Speed: 1500rpm
Technical parameters of generator
Protection level:IP22
Wiring mode:Three-phase four-wire, Y-connection
Generator power: 20kW/25kVA
Adjustment method: AVR (Automatic Voltage Regulator)
Rated voltage: 400V / 230V
Output frequency: 50Hz
Insulation class: H class
Output factor: COSΦ = 0.8 (lag)

Product Name	Diesel generator
Engine	customized
Alternator	customized
Protection	genset shotdown when high water temperature,low oil pressure,shortcuit
Rated Power	20KW,30KW,40KW,50KW,80KW,100KW,200KW,300KW,800KW,1000KW,1200KW,1500KW, 1800KW,2200KW
Cylinder number	3,4,6,8,12cylinders
Cooling System Type	Water Cooling System
Applicable Industries	Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company
Rated Voltage	48V, 110V, 220V, 230V, 240V, 380V, 400V, 415V, 480V
Speed	1500/1800
Frequency	50/60HZ
Diesel Engine	UK, USA, German, Japanese brand engines,4 stroke,water cooled
Alternator model	Stamford/Mecc alte brushless self-excited,IP23,Class H.
Power factor	0.8lagging
Noise level dB(a)	65-95/1m
Excitation	self-excitation
Phase Number and connection	3-phase 4-wire system
Dimension of set (mm)	*14857001000mm~730024402800mm*

Customizable Options: SANROCK POWER Machinery Co., Ltd., offers various customization options for their products, including different genset power and frequency settings. This flexibility allows users to select the most appropriate equipment for their specific requirements, ensuring optimal performance and energy efficiency.

SANROCK POWER Machinery is committed to offering competitive prices without compromising on quality. Their products come with a 3-year warranty period, which provides customers with the assurance and peace of mind necessary to confidently purchase and utilize their generators.

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 10

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 11

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 12

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 13

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 14

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 15

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 16

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 17

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 18

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 19

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 20

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 21

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 22

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 23

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 24

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 25

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 26

Diesel Generator 25kva Industrial and Manufacturing Open Diesel Generator Set Gen Power Diesel Generator 27

FAQ
1. how can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;

2.what can you buy from us?
Screw Air Compressor,Reefer Container Generator,Diesel Generator,Light Tower,Sewage Pump,Centrifugal Pump,Fire Pump System,Mobile Pump Truck

3. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,Express Delivery；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,Western Union,Cash;
Language Spoken:English,Chinese,Spanish
